Southco: C5-21-15-3 Compression Latch, Key Locking, 1-11Mm (.04 - .43 In) Panel Thickness, 1-14Mm (.04 - .55 In) Grip, Zinc Alloy, Powder Coat, Black

Combines latch and door handle capability, for enhanced security. Streamlined looks and easy operation make this compression latch an ideal choice for highly visible installations requiring a secure, sealed fit. Compressive action pulls door tight without rubbing action or wear on pawl or frame. Push-button release pops handle up for convenient use. For use in NEMA 4 and IP-66 applications when installed with optional flange gasket. Threaded adjusting screw and jam nut make it easy to provide necessary grip adjustments over time. /signs, food equipment, HVAC, industrial enclosures, industrial machinery, machine tools, and metal cutting, lawn/garden equipment, marine, networking, railway, telecommunications, vending machines. Hand operated. Standard size series. Latch assembled: No. Head style: locking without dust shutter. 0. 04-0. 43-inches door thickness. 445 N maximum static load NEMA 4/IP-65 sealing is achieved by using optional flange gasket and sealing the mounting screw threads
